Vishay/Dale ISC1812ER560K
- Mfg. Part Number
- ISC1812ER560K
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 56UH 173MA 2.34 OHM
- Datasheet Download
- ISC1812ER560K.pdf
Availability of ISC1812ER560K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.48000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISC1812ER560K, we specialize in Vishay/Dale all series electronic components. ISC1812ER560K can be shipped within 24 hours after order. If you have any demands for ISC1812ER560K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISC1812ER560K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISC1812ER560K
| Internal Part Number | EIS-ISC1812ER560K | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | ISC-1812 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ferrite | |
| Inductance | 56µH | |
| Tolerance | ±10% | |
| Current Rating | 173mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 2.34 Ohm Max | |
| Q @ Freq | 50 @ 2.52MHz | |
| Frequency - Self Resonant | 8MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 2.52MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1812 (4532 Metric) | |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
| Height - Seated (Max) | 0.134" (3.40mm) | |
| Supplier Device Package | 1812 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISC1812ER560K | |
| Related Links | ISC181, ISC1812ER560K Datasheet, Vishay/Dale Distributor | |
ISC1812ER560K Details Description
