Vishay/Dale ISC1812RQ2R2K
- Mfg. Part Number
- ISC1812RQ2R2K
- Manufacturer
- Vishay/Dale
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.2UH 390MA 460 MOHM
- Datasheet Download
- ISC1812RQ2R2K.pdf
Availability of ISC1812RQ2R2K
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.31620
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISC1812RQ2R2K, we specialize in Vishay/Dale all series electronic components. ISC1812RQ2R2K can be shipped within 24 hours after order. If you have any demands for ISC1812RQ2R2K, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISC1812RQ2R2K Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISC1812RQ2R2K
| Internal Part Number | EIS-ISC1812RQ2R2K | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | ISC-1812 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Powdered Iron | |
| Inductance | 2.2µH | |
| Tolerance | ±10% | |
| Current Rating | 390mA | |
| Current - Saturation | - | |
| Shielding | Shielded | |
| DC Resistance (DCR) | 460 mOhm Max | |
| Q @ Freq | 30 @ 7.96MHz | |
| Frequency - Self Resonant | 80MHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 7.96MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 1812 (4532 Metric) | |
| Size / Dimension | 0.177" L x 0.126" W (4.50mm x 3.20mm) | |
| Height - Seated (Max) | 0.134" (3.40mm) | |
| Supplier Device Package | 1812 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISC1812RQ2R2K | |
| Related Links | ISC181, ISC1812RQ2R2K Datasheet, Vishay/Dale Distributor | |
