Intersil ISL6720AARZ
- Mfg. Part Number
- ISL6720AARZ
- Manufacturer
- Intersil
- Product Category
- PMIC - Voltage Regulators - Linear
- Brief Description
- IC REG LDO 5V/ADJ 11DFN
- Datasheet Download
- ISL6720AARZ.pdf
Availability of ISL6720AARZ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISL6720AARZ, we specialize in Intersil all series electronic components. ISL6720AARZ can be shipped within 24 hours after order. If you have any demands for ISL6720AARZ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISL6720AARZ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISL6720AARZ
| Internal Part Number | EIS-ISL6720AARZ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | Multiple Devices 26/Nov/2014 | |
| Standard Package | 75 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - Linear | |
| Series | - | |
| Packaging | Tube | |
| Regulator Topology | Positive Fixed and Adjustable | |
| Voltage - Output | 5V, 0 V ~ 20 V, 0 V ~ 15 V | |
| Current - Output | 25mA, 125mA, 50mA | |
| Voltage - Dropout (Typical) | - | |
| Number of Regulators | 3 | |
| Voltage - Input | 18 V ~ 80 V | |
| Current - Limit (Min) | 30mA, 225mA, 80mA | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 11-VFDFN Exposed Pad | |
| Supplier Device Package | 11-DFN (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISL6720AARZ | |
| Related Links | ISL67, ISL6720AARZ Datasheet, Intersil Distributor | |
ISL6720AARZ Details Description
