Intersil ISL8013AIRZ-T7A
- Mfg. Part Number
- ISL8013AIRZ-T7A
- Manufacturer
- Intersil
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK ADJ 3A SYNC 16QFN
- Datasheet Download
- ISL8013AIRZ-T7A.pdf
Availability of ISL8013AIRZ-T7A
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.19600
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISL8013AIRZ-T7A, we specialize in Intersil all series electronic components. ISL8013AIRZ-T7A can be shipped within 24 hours after order. If you have any demands for ISL8013AIRZ-T7A, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISL8013AIRZ-T7A Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISL8013AIRZ-T7A
| Internal Part Number | EIS-ISL8013AIRZ-T7A | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Application: Industrial Controls | |
| PCN Design/Specification | Copper Bond Wire 26/Mar/2014 | |
| Standard Package | 250 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.8V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 0.8V | |
| Voltage - Output (Max) | 5.5V | |
| Current - Output | 3A | |
| Frequency - Switching | 1MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-VQFN Exposed Pad | |
| Supplier Device Package | 16-QFN (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISL8013AIRZ-T7A | |
| Related Links | ISL8013, ISL8013AIRZ-T7A Datasheet, Intersil Distributor | |
ISL8013AIRZ-T7A Details Description
