Texas Instruments ISO7220ADG4
- Mfg. Part Number
- ISO7220ADG4
- Manufacturer
- Texas Instruments
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 2.5KV GEN PURP 8SOIC
- Datasheet Download
- ISO7220ADG4.pdf
Availability of ISO7220ADG4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.35875
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISO7220ADG4, we specialize in Texas Instruments all series electronic components. ISO7220ADG4 can be shipped within 24 hours after order. If you have any demands for ISO7220ADG4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISO7220ADG4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISO7220ADG4
| Internal Part Number | EIS-ISO7220ADG4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Circuit Isolation Techniques | |
| Manufacturer Product Page | ISO7220ADG4 Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 75 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | - | |
| Packaging | Tube | |
| Technology | Capacitive Coupling | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 2 | |
| Inputs - Side 1/Side 2 | 2/0 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 2500Vrms | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 1Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 475ns, 475ns | |
| Pulse Width Distortion (Max) | 14ns | |
| Rise / Fall Time (Typ) | 1ns, 1ns | |
| Voltage - Supply | 3 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISO7220ADG4 | |
| Related Links | ISO72, ISO7220ADG4 Datasheet, Texas Instruments Distributor | |
