Texas Instruments ISO7231ADW
.jpg)
- Mfg. Part Number
- ISO7231ADW
- Manufacturer
- Texas Instruments
- Product Category
- Digital Isolators
- Brief Description
- DGTL ISO 4KV 3CH GEN PURP 16SOIC
- Datasheet Download
- ISO7231ADW.pdf
Availability of ISO7231ADW
Available Quantity
5980 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.20000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of ISO7231ADW, we specialize in Texas Instruments all series electronic components. ISO7231ADW can be shipped within 24 hours after order. If you have any demands for ISO7231ADW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- ISO7231ADW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
ISO7231ADW
| Internal Part Number | EIS-ISO7231ADW | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Circuit Isolation Techniques | |
| PCN Design/Specification | 16DW Datasheet Update 17/Sep/2013 | |
| Manufacturer Product Page | ISO7231ADW Specifications | |
| Standard Package | 40 | |
| Category | Isolators | |
| Family | Digital Isolators | |
| Series | - | |
| Packaging | Tube | |
| Technology | Capacitive Coupling | |
| Type | General Purpose | |
| Isolated Power | No | |
| Number of Channels | 3 | |
| Inputs - Side 1/Side 2 | 2/1 | |
| Channel Type | Unidirectional | |
| Voltage - Isolation | 4000Vpk | |
| Common Mode Transient Immunity (Min) | 25kV/µs | |
| Data Rate | 1Mbps | |
| Propagation Delay tpLH / tpHL (Max) | 95ns, 95ns | |
| Pulse Width Distortion (Max) | 10ns | |
| Rise / Fall Time (Typ) | 2ns, 2ns | |
| Voltage - Supply | 3.15 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 16-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 16-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | ISO7231ADW | |
| Related Links | ISO72, ISO7231ADW Datasheet, Texas Instruments Distributor | |
ISO7231ADW Details Description
