IXYS Corporation IXTA1R6N100D2
- Mfg. Part Number
- IXTA1R6N100D2
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Single
- Brief Description
- MOSFET N-CH 1000V 1.6A D2PAK
- Datasheet Download
- IXTA1R6N100D2.pdf
Availability of IXTA1R6N100D2
Available Quantity
5824 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.01400
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXTA1R6N100D2, we specialize in IXYS Corporation all series electronic components. IXTA1R6N100D2 can be shipped within 24 hours after order. If you have any demands for IXTA1R6N100D2, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXTA1R6N100D2 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXTA1R6N100D2
| Internal Part Number | EIS-IXTA1R6N100D2 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Depletion-Mode D2™ Power MOSFETs | |
| Standard Package | 50 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tube | |
| FET Type | MOSFET N-Channel, Metal Oxide | |
| FET Feature | Depletion Mode | |
| Drain to Source Voltage (Vdss) | 1000V (1kV) | |
| Current - Continuous Drain (Id) @ 25°C | 1.6A (Tc) | |
| Rds On (Max) @ Id, Vgs | 10 Ohm @ 800mA, 0V | |
| Vgs(th) (Max) @ Id | - | |
| Gate Charge (Qg) @ Vgs | 27nC @ 5V | |
| Input Capacitance (Ciss) @ Vds | 645pF @ 25V | |
| Power - Max | 100W | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-3, D²Pak (2 Leads + Tab), TO-263AB | |
| Supplier Device Package | TO-263 (IXTA) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXTA1R6N100D2 | |
| Related Links | IXTA1R, IXTA1R6N100D2 Datasheet, IXYS Corporation Distributor | |
