IXYS Corporation IXTH8P50
- Mfg. Part Number
- IXTH8P50
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Single
- Brief Description
- MOSFET P-CH 500V 8A TO-247
- Datasheet Download
- IXTH8P50.pdf
Availability of IXTH8P50
Available Quantity
5412 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.16110
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXTH8P50, we specialize in IXYS Corporation all series electronic components. IXTH8P50 can be shipped within 24 hours after order. If you have any demands for IXTH8P50, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXTH8P50 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXTH8P50
| Internal Part Number | EIS-IXTH8P50 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 30 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Single | |
| Series | - | |
| Packaging | Tube | |
| FET Type | MOSFET P-Channel, Metal Oxide | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 500V | |
| Current - Continuous Drain (Id) @ 25°C | 8A (Tc) | |
| Rds On (Max) @ Id, Vgs | 1.2 Ohm @ 4A, 10V | |
| Vgs(th) (Max) @ Id | 5V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 130nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 3400pF @ 25V | |
| Power - Max | 180W | |
| Mounting Type | Through Hole | |
| Package / Case | TO-247-3 | |
| Supplier Device Package | TO-247 (IXTH) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXTH8P50 | |
| Related Links | IXTH, IXTH8P50 Datasheet, IXYS Corporation Distributor | |
IXTH8P50 Details Description
