IXYS Corporation IXTL2X240N055T
- Mfg. Part Number
- IXTL2X240N055T
- Manufacturer
- IXYS Corporation
- Product Category
- FETs - Arrays
- Brief Description
- MOSFET 2N-CH 55V 140A ISOPLUS I5
- Datasheet Download
- IXTL2X240N055T.pdf
Availability of IXTL2X240N055T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of IXTL2X240N055T, we specialize in IXYS Corporation all series electronic components. IXTL2X240N055T can be shipped within 24 hours after order. If you have any demands for IXTL2X240N055T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- IXTL2X240N055T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
IXTL2X240N055T
| Internal Part Number | EIS-IXTL2X240N055T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| PCN Obsolescence/ EOL | IXT Series 30/Oct/2012 | |
| Standard Package | 25 | |
| Category | Discrete Semiconductor Products | |
| Family | FETs - Arrays | |
| Series | TrenchMV™ | |
| Packaging | Tube | |
| FET Type | 2 N-Channel (Dual) | |
| FET Feature | Standard | |
| Drain to Source Voltage (Vdss) | 55V | |
| Current - Continuous Drain (Id) @ 25°C | 140A | |
| Rds On (Max) @ Id, Vgs | 4.4 mOhm @ 50A, 10V | |
| Vgs(th) (Max) @ Id | 4V @ 250µA | |
| Gate Charge (Qg) @ Vgs | 170nC @ 10V | |
| Input Capacitance (Ciss) @ Vds | 7600pF @ 25V | |
| Power - Max | 150W | |
| Mounting Type | Through Hole | |
| Package / Case | ISOPLUSi5-Pak™ | |
| Supplier Device Package | ISOPLUSi5-Pak™ | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | IXTL2X240N055T | |
| Related Links | IXTL2X2, IXTL2X240N055T Datasheet, IXYS Corporation Distributor | |
IXTL2X240N055T Details Description
