Souriau Connection Technology JBXEA2G12FQSXS
- Mfg. Part Number
- JBXEA2G12FQSXS
- Manufacturer
- Souriau Connection Technology
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 12POS PNL MNT SKT RA
- Datasheet Download
- JBXEA2G12FQSXS.pdf
Availability of JBXEA2G12FQSXS
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 64.01500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JBXEA2G12FQSXS, we specialize in Souriau Connection Technology all series electronic components. JBXEA2G12FQSXS can be shipped within 24 hours after order. If you have any demands for JBXEA2G12FQSXS, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JBXEA2G12FQSXS Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JBXEA2G12FQSXS
| Internal Part Number | EIS-JBXEA2G12FQSXS | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | JBX | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 12 | |
| Shell Size - Insert | 2 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Bulkhead; Through Hole, Right Angle | |
| Termination | Solder | |
| Fastening Type | Push-Pull | |
| Orientation | G | |
| Ingress Protection | IP40 | |
| Shell Material, Finish | Brass, Chrome over Nickel | |
| Contact Finish | Gold | |
| Features | Shielded | |
| Contact Finish Thickness | 19.7µin (0.50µm) | |
| Current Rating | 7A | |
| Voltage - Rated | 830VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JBXEA2G12FQSXS | |
| Related Links | JBXEA2G, JBXEA2G12FQSXS Datasheet, Souriau Connection Technology Distributor | |
JBXEA2G12FQSXS Details Description
