NKK Switches JPL26B/U
- Mfg. Part Number
- JPL26B/U
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSH DPST 16A 125V
- Datasheet Download
- JPL26B/U.pdf
Availability of JPL26B/U
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 12.60000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JPL26B/U, we specialize in NKK Switches all series electronic components. JPL26B/U can be shipped within 24 hours after order. If you have any demands for JPL26B/U, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JPL26B/U Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JPL26B/U
| Internal Part Number | EIS-JPL26B/U | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Pushbutton Switches | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | JP | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | DPST | |
| Switch Function | Off-On | |
| Current Rating | 16A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Rectangular, Button | |
| Color - Actuator/Cap | - | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | Tactile Feedback | |
| Panel Cutout Dimensions | Rectangular - 28.00mm x 21.20mm | |
| Operating Temperature | -10°C ~ 70°C | |
| Mechanical Life | 25,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JPL26B/U | |
| Related Links | JPL2, JPL26B/U Datasheet, NKK Switches Distributor | |
