NKK Switches JWL11RA2A/UCV
- Mfg. Part Number
- JWL11RA2A/UCV
- Manufacturer
- NKK Switches
- Product Category
- Rocker Switches
- Brief Description
- SWITCH ROCKER SPST 16A 125V
- Datasheet Download
- JWL11RA2A/UCV.pdf
Availability of JWL11RA2A/UCV
Available Quantity
5131 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.20725
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of JWL11RA2A/UCV, we specialize in NKK Switches all series electronic components. JWL11RA2A/UCV can be shipped within 24 hours after order. If you have any demands for JWL11RA2A/UCV, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- JWL11RA2A/UCV Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
JWL11RA2A/UCV
| Internal Part Number | EIS-JWL11RA2A/UCV | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics Tough Environments 3D CAD Models Value Added and Custom Switch Capabilities | |
| RoHS Information | JW Series, Cert of Compliance | |
| 3D Model | JWL11RA2A | |
| PCN Design/Specification | JWM/JWL/JWLW Rockers UL Factory Code 15/Aug/2014 JW Series 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Rocker Switches | |
| Series | JW | |
| Packaging | Bulk | |
| Circuit | SPST | |
| Switch Function | On-Off | |
| Current Rating | 16A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Concave (Curved) | |
| Color - Actuator/Cap | Black | |
| Actuator Marking | O - | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Panel Mount, Snap-In | |
| Termination Style | Solder, Quick Connect - 0.187" (4.7mm) | |
| Ingress Protection | Dust Proof | |
| Features | Epoxy Sealed Terminals | |
| Panel Cutout Dimensions | Rectangular - 29.50mm x 20.50mm | |
| Operating Temperature | -25°C ~ 70°C | |
| Mechanical Life | 25,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | JWL11RA2A/UCV | |
| Related Links | JWL11R, JWL11RA2A/UCV Datasheet, NKK Switches Distributor | |
