NKK Switches KB26SKW01-5D12-AB
- Mfg. Part Number
- KB26SKW01-5D12-AB
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON DPDT 1A 125V
- Datasheet Download
- KB26SKW01-5D12-AB.pdf
Availability of KB26SKW01-5D12-AB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 17.37000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KB26SKW01-5D12-AB, we specialize in NKK Switches all series electronic components. KB26SKW01-5D12-AB can be shipped within 24 hours after order. If you have any demands for KB26SKW01-5D12-AB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KB26SKW01-5D12-AB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KB26SKW01-5D12-AB
| Internal Part Number | EIS-KB26SKW01-5D12-AB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | Series, Cert of Compliance | |
| Featured Product | Pushbutton Switches | |
| PCN Design/Specification | KB Series Surface Finish 08/Feb/2010 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | KB | |
| Packaging | Bulk | |
| Type | Standard, Illuminated | |
| Circuit | DPDT | |
| Switch Function | On-On | |
| Current Rating | 1A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Square, Button | |
| Color - Actuator/Cap | Black (White Window) | |
| Illumination Type, Color | LED, Amber | |
| Illumination Voltage (Nominal) | 12 VDC | |
| Mounting Type | Panel Mount, Front | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Panel Cutout Dimensions | Circular - 12.30mm Dia | |
| Operating Temperature | -25°C ~ 50°C | |
| Mechanical Life | 100,000 Cycles | |
| Electrical Life | 50,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KB26SKW01-5D12-AB | |
| Related Links | KB26SKW0, KB26SKW01-5D12-AB Datasheet, NKK Switches Distributor | |
KB26SKW01-5D12-AB Details Description
