ITT Cannon, LLC KJB7T15F18SD
- Mfg. Part Number
- KJB7T15F18SD
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN RCPT 18POS JAM NUT SKT
- Datasheet Download
- KJB7T15F18SD.pdf
Availability of KJB7T15F18SD
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 59.80760
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KJB7T15F18SD, we specialize in ITT Cannon, LLC all series electronic components. KJB7T15F18SD can be shipped within 24 hours after order. If you have any demands for KJB7T15F18SD, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KJB7T15F18SD Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KJB7T15F18SD
| Internal Part Number | EIS-KJB7T15F18SD | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-38999 Series III, KJB | |
| Packaging | Bulk | |
| Connector Type | Receptacle, Female Sockets | |
| Number of Positions | 18 | |
| Shell Size - Insert | 15-18 | |
| Shell Size, MIL | - | |
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut | |
| Termination | Crimp | |
| Fastening Type | Threaded | |
| Orientation | D | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum Alloy, Nickel Plated, Electroless | |
| Contact Finish | Gold | |
| Features | - | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | - | |
| Voltage - Rated | - | |
| Operating Temperature | -65°C ~ 200°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KJB7T15F18SD | |
| Related Links | KJB7T1, KJB7T15F18SD Datasheet, ITT Cannon, LLC Distributor | |
KJB7T15F18SD Details Description
