ITT Cannon, LLC KPSE06F16-8SDX
- Mfg. Part Number
- KPSE06F16-8SDX
- Manufacturer
- ITT Cannon, LLC
- Product Category
- Circular Connectors
- Brief Description
- CONN PLUG 8POS W/SKT INLINE
- Datasheet Download
- KPSE06F16-8SDX.pdf
Availability of KPSE06F16-8SDX
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 57.27220
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of KPSE06F16-8SDX, we specialize in ITT Cannon, LLC all series electronic components. KPSE06F16-8SDX can be shipped within 24 hours after order. If you have any demands for KPSE06F16-8SDX, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- KPSE06F16-8SDX Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
KPSE06F16-8SDX
| Internal Part Number | EIS-KPSE06F16-8SDX | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Circular Connectors | |
| Series | MIL-DTL-26482 Series I, KPSE | |
| Packaging | Bulk | |
| Connector Type | Plug, Female Sockets | |
| Number of Positions | 8 | |
| Shell Size - Insert | 16-8 | |
| Shell Size, MIL | - | |
| Mounting Type | Free Hanging (In-Line) | |
| Termination | Crimp | |
| Fastening Type | Bayonet Lock | |
| Orientation | N (Normal) | |
| Ingress Protection | Environment Resistant | |
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated | |
| Contact Finish | Gold | |
| Features | Strain Relief | |
| Contact Finish Thickness | 50µin (1.27µm) | |
| Current Rating | 13A | |
| Voltage - Rated | 1000VAC, 1400VDC | |
| Operating Temperature | -55°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | KPSE06F16-8SDX | |
| Related Links | KPSE06F, KPSE06F16-8SDX Datasheet, ITT Cannon, LLC Distributor | |
