Johanson Technology Inc. L-07W5N6SV4T
.jpg)
- Mfg. Part Number
- L-07W5N6SV4T
- Manufacturer
- Johanson Technology Inc.
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 5.6NH 760MA 83 MOHM
- Datasheet Download
- L-07W5N6SV4T.pdf
Availability of L-07W5N6SV4T
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of L-07W5N6SV4T, we specialize in Johanson Technology Inc. all series electronic components. L-07W5N6SV4T can be shipped within 24 hours after order. If you have any demands for L-07W5N6SV4T, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- L-07W5N6SV4T Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
L-07W5N6SV4T
| Internal Part Number | EIS-L-07W5N6SV4T | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 10,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Ceramic | |
| Inductance | 5.6nH | |
| Tolerance | ±0.3nH | |
| Current Rating | 760mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 83 mOhm Max | |
| Q @ Freq | 20 @ 250MHz | |
| Frequency - Self Resonant | 5.8GHz | |
| Operating Temperature | -40°C ~ 125°C | |
| Frequency - Test | 250MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height - Seated (Max) | 0.024" (0.60mm) | |
| Supplier Device Package | 0402 (1005 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | L-07W5N6SV4T | |
| Related Links | L-07W5, L-07W5N6SV4T Datasheet, Johanson Technology Inc. Distributor | |
