Sanken LC5511D
- Mfg. Part Number
- LC5511D
- Manufacturer
- Sanken
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver AC DC Offline Switcher 8-DIP
- Datasheet Download
- LC5511D.pdf
Availability of LC5511D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.01250
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LC5511D, we specialize in Sanken all series electronic components. LC5511D can be shipped within 24 hours after order. If you have any demands for LC5511D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LC5511D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LC5511D
| Internal Part Number | EIS-LC5511D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Bulk | |
| Type | AC DC Offline Switcher | |
| Topology | - | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | - | |
| Voltage - Supply (Max) | 20V | |
| Voltage - Output | - | |
| Current - Output / Channel | - | |
| Frequency | - | |
| Dimming | - | |
| Applications | - | |
| Operating Temperature | -55°C ~ 125°C (TA) | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads | |
| Supplier Device Package | 8-DIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LC5511D | |
| Related Links | LC5, LC5511D Datasheet, Sanken Distributor | |
LC5511D Details Description
