Panduit LCAS8-14F-L
- Mfg. Part Number
- LCAS8-14F-L
- Manufacturer
- Panduit
- Product Category
- Terminals - Rectangular Connectors
- Brief Description
- LUG COPPER 1 HOLE
- Datasheet Download
- LCAS8-14F-L.pdf
Availability of LCAS8-14F-L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.23000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LCAS8-14F-L, we specialize in Panduit all series electronic components. LCAS8-14F-L can be shipped within 24 hours after order. If you have any demands for LCAS8-14F-L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LCAS8-14F-L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LCAS8-14F-L
| Internal Part Number | EIS-LCAS8-14F-L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1 | |
| Category | Connectors, Interconnects | |
| Family | Terminals - Rectangular Connectors | |
| Series | Pan-Lug® | |
| Packaging | Bulk | |
| Terminal Type | Rectangular Tongue | |
| Stud/Tab Size | 1/4 Stud | |
| Terminal Style | Single Stud Hole | |
| Tab Thickness | 0.070" (1.78mm) | |
| Length - Overall | - | |
| Width - Outer Edges | 0.480" (12.19mm) | |
| Mounting Type | Free Hanging (In-Line), Right Angle | |
| Termination | Crimp, Barrel | |
| Wire Gauge | 8 AWG | |
| Insulation | Non-Insulated | |
| Features | - | |
| Color | Red | |
| Contact Finish | Electro-Tin | |
| Contact Material | Copper | |
| Diameter - Barrel ID | 0.180" (4.57mm) | |
| Diameter - Barrel OD | 0.270" (6.86mm) | |
| Diameter - Ring ID | 0.270" (6.86mm) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LCAS8-14F-L | |
| Related Links | LCAS8, LCAS8-14F-L Datasheet, Panduit Distributor | |
