C&K Components LCS05060T19SDC
- Mfg. Part Number
- LCS05060T19SDC
- Manufacturer
- C&K Components
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SW SNPACT SPDT 125VAC 6A SEALED
- Datasheet Download
- LCS05060T19SDC.pdf
Availability of LCS05060T19SDC
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.86000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LCS05060T19SDC, we specialize in C&K Components all series electronic components. LCS05060T19SDC can be shipped within 24 hours after order. If you have any demands for LCS05060T19SDC, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LCS05060T19SDC Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LCS05060T19SDC
| Internal Part Number | EIS-LCS05060T19SDC | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Sub-Miniature Snap Switches | |
| PCN Part Number | LCA and LCS Series 22/Oct/2010 | |
| Standard Package | 100 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | LCS | |
| Packaging | Bulk | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 6A (AC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | - | |
| Actuator Type | Lever, Straight | |
| Mounting Type | Chassis Mount | |
| Termination Style | Solder Lug | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 10gf | |
| Release Force | - | |
| Pretravel | 0.283" (7.2mm) | |
| Differential Travel | - | |
| Overtravel | 0.079" (2.0mm) | |
| Operating Position | 0.406" (10.3mm) | |
| Mechanical Life | - | |
| Electrical Life | 6,000 Cycles | |
| Operating Temperature | -40°C ~ 125°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LCS05060T19SDC | |
| Related Links | LCS0506, LCS05060T19SDC Datasheet, C&K Components Distributor | |
LCS05060T19SDC Details Description
