Excelsys Technologies Ltd LDB200-024SW
- Mfg. Part Number
- LDB200-024SW
- Manufacturer
- Excelsys Technologies Ltd
- Product Category
- LED Supplies
- Brief Description
- LED SUPPLY CC/CV AC/DC 12-24V
- Datasheet Download
- LDB200-024SW.pdf
Availability of LDB200-024SW
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LDB200-024SW, we specialize in Excelsys Technologies Ltd all series electronic components. LDB200-024SW can be shipped within 24 hours after order. If you have any demands for LDB200-024SW, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LDB200-024SW Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LDB200-024SW
| Internal Part Number | EIS-LDB200-024SW | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| RoHS Information | LED RoHS Delcaration | |
| Design Resources | Lighting Product Selector | |
| Standard Package | 5 | |
| Category | Power Supplies - External/Internal (Off-Board) | |
| Family | LED Supplies | |
| Series | LDB200 | |
| Type | Constant Current, Voltage | |
| Topology | AC DC Converter | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 90VAC | |
| Voltage - Input (Max) | 305VAC | |
| Voltage - Output | 12 ~ 24 V | |
| Current - Output (Max) | 8.5A | |
| Power (Watts) | 200W | |
| Voltage - Isolation | 3.75kV (3750V) | |
| Dimming | - | |
| Features | OCP, OTP, OVP, SCP | |
| Ratings | IP67 | |
| Operating Temperature | -30°C ~ 70°C | |
| Efficiency | 92.5% | |
| Termination Style | Wire Leads | |
| Size / Dimension | 8.78" L x 2.48" W x 1.38" H (223.0mm x 63.0mm x 35.0mm) | |
| Mounting Type | Chassis Mount | |
| Approvals | CE, CSA, cULus, EN | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LDB200-024SW | |
| Related Links | LDB200, LDB200-024SW Datasheet, Excelsys Technologies Ltd Distributor | |
