Texas Instruments LM25101ASDX/NOPB
- Mfg. Part Number
- LM25101ASDX/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Gate Drivers
- Brief Description
- IC GATE DVR HI/LO SIDE 10WSON
- Datasheet Download
- LM25101ASDX/NOPB.pdf
Availability of LM25101ASDX/NOPB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.40625
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM25101ASDX/NOPB, we specialize in Texas Instruments all series electronic components. LM25101ASDX/NOPB can be shipped within 24 hours after order. If you have any demands for LM25101ASDX/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM25101ASDX/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM25101ASDX/NOPB
| Internal Part Number | EIS-LM25101ASDX/NOPB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 4,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Gate Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Configuration | High and Low Side, Synchronous | |
| Input Type | Non-Inverting | |
| Delay Time | 26ns | |
| Current - Peak | 3A | |
| Number of Configurations | 1 | |
| Number of Outputs | 2 | |
| High Side Voltage - Max (Bootstrap) | 100V | |
| Voltage - Supply | 9 V ~ 14 V | |
| Operating Temperature | -40°C ~ 125°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 10-WDFN Exposed Pad | |
| Supplier Device Package | 10-WSON (4x4) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM25101ASDX/NOPB | |
| Related Links | LM25101A, LM25101ASDX/NOPB Datasheet, Texas Instruments Distributor | |
