Texas Instruments LM285BXZ-1.2/LFT4
- Mfg. Part Number
- LM285BXZ-1.2/LFT4
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SHUNT 1.235V TO92-3
- Datasheet Download
- LM285BXZ-1.2/LFT4.pdf
Availability of LM285BXZ-1.2/LFT4
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.03410
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM285BXZ-1.2/LFT4, we specialize in Texas Instruments all series electronic components. LM285BXZ-1.2/LFT4 can be shipped within 24 hours after order. If you have any demands for LM285BXZ-1.2/LFT4, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM285BXZ-1.2/LFT4 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM285BXZ-1.2/LFT4
| Internal Part Number | EIS-LM285BXZ-1.2/LFT4 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 2,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Bulk | |
| Reference Type | Shunt | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 1.235V | |
| Voltage - Output (Max) | - | |
| Current - Output | 20mA | |
| Tolerance | ±1% | |
| Temperature Coefficient | 30ppm/°C | |
| Noise - 0.1Hz to 10Hz | - | |
| Noise - 10Hz to 10kHz | 60µVrms | |
| Voltage - Input | - | |
| Current - Supply | - | |
| Current - Cathode | 10µA | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Through Hole | |
| Package / Case | TO-226-3, TO-92-3 (TO-226AA) | |
| Supplier Device Package | TO-92-3 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM285BXZ-1.2/LFT4 | |
| Related Links | LM285BXZ, LM285BXZ-1.2/LFT4 Datasheet, Texas Instruments Distributor | |
LM285BXZ-1.2/LFT4 Details Description
