ON Semiconductor LM2904DG
- Mfg. Part Number
- LM2904DG
- Manufacturer
- ON Semiconductor
- Product Category
- Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
- Brief Description
- IC OPAMP GP 1MHZ 8SOIC
- Datasheet Download
- LM2904DG.pdf
Availability of LM2904DG
Available Quantity
9123 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.12222
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM2904DG, we specialize in ON Semiconductor all series electronic components. LM2904DG can be shipped within 24 hours after order. If you have any demands for LM2904DG, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM2904DG Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM2904DG
| Internal Part Number | EIS-LM2904DG | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Assembly/Origin | SOIC08 Copper Wire 04/Jul/2013 | |
| Standard Package | 98 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps | |
| Series | - | |
| Packaging | Tube | |
| Amplifier Type | General Purpose | |
| Number of Circuits | 2 | |
| Output Type | - | |
| Slew Rate | 0.6 V/µs | |
| Gain Bandwidth Product | 1MHz | |
| -3db Bandwidth | - | |
| Current - Input Bias | 45nA | |
| Voltage - Input Offset | 2mV | |
| Current - Supply | 1.5mA | |
| Current - Output / Channel | 40mA | |
| Voltage - Supply, Single/Dual (±) | 3 V ~ 32 V, ±1.5 V ~ 16 V | |
| Operating Temperature | -40°C ~ 105°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) | |
| Supplier Device Package | 8-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM2904DG | |
| Related Links | LM29, LM2904DG Datasheet, ON Semiconductor Distributor | |
LM2904DG Details Description
