Texas Instruments LM311N/NOPB
- Mfg. Part Number
- LM311N/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- Linear - Comparators
- Brief Description
- IC VOLTAGE COMPARATOR 8-DIP
- Datasheet Download
- LM311N/NOPB.pdf
Availability of LM311N/NOPB
Available Quantity
8750 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.29640
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM311N/NOPB, we specialize in Texas Instruments all series electronic components. LM311N/NOPB can be shipped within 24 hours after order. If you have any demands for LM311N/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM311N/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM311N/NOPB
| Internal Part Number | EIS-LM311N/NOPB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Mold Compound Update 04/Dec/2014 | |
| Manufacturer Product Page | LM311N/NOPB Specifications | |
| Standard Package | 40 | |
| Category | Integrated Circuits (ICs) | |
| Family | Linear - Comparators | |
| Series | - | |
| Packaging | Tube | |
| Type | General Purpose | |
| Number of Elements | 1 | |
| Output Type | DTL, MOS, Open-Collector, Open-Emitter, RTL, TTL | |
| Voltage - Supply, Single/Dual (±) | 5 V ~ 36 V, ±2.5 V ~ 18 V | |
| Voltage - Input Offset (Max) | 7.5mV @ ±15V | |
| Current - Input Bias (Max) | 0.25µA @ ±15V | |
| Current - Output (Typ) | 50mA | |
| Current - Quiescent (Max) | 7.5mA | |
| CMRR, PSRR (Typ) | - | |
| Propagation Delay (Max) | - | |
| Hysteresis | - | |
| Operating Temperature | 0°C ~ 70°C | |
| Package / Case | 8-DIP (0.300", 7.62mm) | |
| Mounting Type | Through Hole | |
| Supplier Device Package | 8-PDIP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM311N/NOPB | |
| Related Links | LM311, LM311N/NOPB Datasheet, Texas Instruments Distributor | |
