Texas Instruments LM3492MHX/NOPB
- Mfg. Part Number
- LM3492MHX/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver DC DC Regulator 50mA - 250mA Backlight 20-HTSSOP
- Datasheet Download
- LM3492MHX/NOPB.pdf
Availability of LM3492MHX/NOPB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.12500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM3492MHX/NOPB, we specialize in Texas Instruments all series electronic components. LM3492MHX/NOPB can be shipped within 24 hours after order. If you have any demands for LM3492MHX/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM3492MHX/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM3492MHX/NOPB
| Internal Part Number | EIS-LM3492MHX/NOPB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LED Lighting Driver Solutions | |
| Design Resources | Lighting Product Selector LM3492 Design with WEBENCH® Power Designer | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| Reference Design Library | LM3492EVAL: 38V max @ 150mA (x2), 9 ~ 16V in | |
| PCN Assembly/Origin | Wafer Fab Qualification 07/Oct/2014 | |
| PCN Packaging | Pack Material Update 11/May/2015 Packing Material Revision A 19/May/2015 | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 2,500 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | DC DC Regulator | |
| Topology | Step-Up (Boost) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 2 | |
| Voltage - Supply (Min) | 4.5V | |
| Voltage - Supply (Max) | 65V | |
| Voltage - Output | - | |
| Current - Output / Channel | 50mA ~ 250mA | |
| Frequency | 200kHz ~ 1MHz | |
| Dimming | - | |
| Applications | Backlight | |
| Operating Temperature | -40°C ~ 125°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-TSSOP (0.173", 4.40mm Width) Exposed Pad | |
| Supplier Device Package | 20-HTSSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM3492MHX/NOPB | |
| Related Links | LM3492M, LM3492MHX/NOPB Datasheet, Texas Instruments Distributor | |
