Texas Instruments LM4120IM5-1.8/NOPB
- Mfg. Part Number
- LM4120IM5-1.8/NOPB
- Manufacturer
- Texas Instruments
- Product Category
- PMIC - Voltage Reference
- Brief Description
- IC VREF SERIES 1.8V SOT23-5
- Datasheet Download
- LM4120IM5-1.8/NOPB.pdf
Availability of LM4120IM5-1.8/NOPB
Available Quantity
5515 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.78750
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LM4120IM5-1.8/NOPB, we specialize in Texas Instruments all series electronic components. LM4120IM5-1.8/NOPB can be shipped within 24 hours after order. If you have any demands for LM4120IM5-1.8/NOPB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LM4120IM5-1.8/NOPB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LM4120IM5-1.8/NOPB
| Internal Part Number | EIS-LM4120IM5-1.8/NOPB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | Create your power design now with TI’s WEBENCH® Designer | |
| PCN Design/Specification | Copper Wire Update 14/May/2015 | |
| Manufacturer Product Page | LM4120IM5-1.8/NOPB Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Reference | |
| Series | - | |
| Packaging | Cut Tape (CT) | |
| Reference Type | Series | |
| Output Type | Fixed | |
| Voltage - Output (Min/Fixed) | 1.8V | |
| Voltage - Output (Max) | - | |
| Current - Output | 5mA | |
| Tolerance | ±0.5% | |
| Temperature Coefficient | 50ppm/°C | |
| Noise - 0.1Hz to 10Hz | 20µVp-p | |
| Noise - 10Hz to 10kHz | 36µVp-p | |
| Voltage - Input | 2 V ~ 12 V | |
| Current - Supply | 275µA | |
| Current - Cathode | - | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | SC-74A, SOT-753 | |
| Supplier Device Package | SOT-23-5 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LM4120IM5-1.8/NOPB | |
| Related Links | LM4120IM5, LM4120IM5-1.8/NOPB Datasheet, Texas Instruments Distributor | |
LM4120IM5-1.8/NOPB Details Description
