Murata Electronics North America LQP03TN2N9C02D
- Mfg. Part Number
- LQP03TN2N9C02D
- Manufacturer
- Murata Electronics North America
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 2.9NH 500MA 200 MOHM
- Datasheet Download
- LQP03TN2N9C02D.pdf
Availability of LQP03TN2N9C02D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.01275
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LQP03TN2N9C02D, we specialize in Murata Electronics North America all series electronic components. LQP03TN2N9C02D can be shipped within 24 hours after order. If you have any demands for LQP03TN2N9C02D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LQP03TN2N9C02D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LQP03TN2N9C02D
| Internal Part Number | EIS-LQP03TN2N9C02D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Chip RF Inductors | |
| Standard Package | 15,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | LQP03TN_02 | |
| Packaging | Tape & Reel (TR) | |
| Type | Thin Film | |
| Material - Core | - | |
| Inductance | 2.9nH | |
| Tolerance | ±0.2nH | |
| Current Rating | 500mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 200 mOhm Max | |
| Q @ Freq | 14 @ 500MHz | |
| Frequency - Self Resonant | 6GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 500MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0201 (0603 Metric) | |
| Size / Dimension | 0.024" L x 0.012" W (0.60mm x 0.30mm) | |
| Height - Seated (Max) | 0.013" (0.33mm) | |
| Supplier Device Package | 0201 (0603 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LQP03TN2N9C02D | |
| Related Links | LQP03TN, LQP03TN2N9C02D Datasheet, Murata Electronics North America Distributor | |
LQP03TN2N9C02D Details Description
