Artesyn Embedded Technologies LQS30A24-3V3AJ
- Mfg. Part Number
- LQS30A24-3V3AJ
- Manufacturer
- Artesyn Embedded Technologies
- Product Category
- DC DC Converters
- Brief Description
- DC/DC CONVERTER 3.3V 200W
- Datasheet Download
- LQS30A24-3V3AJ.pdf
Availability of LQS30A24-3V3AJ
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LQS30A24-3V3AJ, we specialize in Artesyn Embedded Technologies all series electronic components. LQS30A24-3V3AJ can be shipped within 24 hours after order. If you have any demands for LQS30A24-3V3AJ, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LQS30A24-3V3AJ Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LQS30A24-3V3AJ
| Internal Part Number | EIS-LQS30A24-3V3AJ | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 48 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | LQS | |
| Packaging | Tray | |
| Type | Isolated Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 18V | |
| Voltage - Input (Max) | 36V | |
| Voltage - Output 1 | 3.3V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 30A | |
| Power (Watts) - Manufacture Series | 200W | |
| Voltage - Isolation | 2.25kV (2250V) | |
| Features | Remote On/Off, OTP, OVP, SCP, UVLO | |
| Mounting Type | Through Hole | |
| Package / Case | 8-DIP Module, 1/4 Brick | |
| Size / Dimension | 2.30" L x 1.45" W x 0.33" H (58.4mm x 36.8mm x 8.4mm) | |
| Operating Temperature | -40°C ~ 85°C | |
| Efficiency | 89.5% | |
| Power (Watts) - Max | 99W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LQS30A24-3V3AJ | |
| Related Links | LQS30A2, LQS30A24-3V3AJ Datasheet, Artesyn Embedded Technologies Distributor | |
LQS30A24-3V3AJ Details Description
