Murata Electronics North America LQW15AN7N5H00D
- Mfg. Part Number
- LQW15AN7N5H00D
- Manufacturer
- Murata Electronics North America
- Product Category
- Fixed Inductors
- Brief Description
- FIXED IND 7.5NH 570MA 130 MOHM
- Datasheet Download
- LQW15AN7N5H00D.pdf
Availability of LQW15AN7N5H00D
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 0.04568
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LQW15AN7N5H00D, we specialize in Murata Electronics North America all series electronic components. LQW15AN7N5H00D can be shipped within 24 hours after order. If you have any demands for LQW15AN7N5H00D, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LQW15AN7N5H00D Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LQW15AN7N5H00D
| Internal Part Number | EIS-LQW15AN7N5H00D | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Inductor Products Chip RF Inductors | |
| Standard Package | 10,000 | |
| Category | Inductors, Coils, Chokes | |
| Family | Fixed Inductors | |
| Series | LQW15A_00 | |
| Packaging | Tape & Reel (TR) | |
| Type | Wirewound | |
| Material - Core | Non-Magnetic | |
| Inductance | 7.5nH | |
| Tolerance | ±3% | |
| Current Rating | 570mA | |
| Current - Saturation | - | |
| Shielding | Unshielded | |
| DC Resistance (DCR) | 130 mOhm Max | |
| Q @ Freq | 25 @ 250MHz | |
| Frequency - Self Resonant | 6GHz | |
| Operating Temperature | -55°C ~ 125°C | |
| Frequency - Test | 100MHz | |
| Mounting Type | Surface Mount | |
| Package / Case | 0402 (1005 Metric) | |
| Size / Dimension | 0.039" L x 0.020" W (1.00mm x 0.50mm) | |
| Height - Seated (Max) | 0.024" (0.60mm) | |
| Supplier Device Package | 0402 (1005 Metric) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LQW15AN7N5H00D | |
| Related Links | LQW15AN, LQW15AN7N5H00D Datasheet, Murata Electronics North America Distributor | |
LQW15AN7N5H00D Details Description
