Honeywell Sensing and Productivity Solutions LSR6B
- Mfg. Part Number
- LSR6B
- Manufacturer
- Honeywell Sensing and Productivity Solutions
- Product Category
- Snap Action, Limit Switches
- Brief Description
- SWITCH 2NC 2NO DPDT SNAP 120V
- Datasheet Download
- LSR6B.pdf
Availability of LSR6B
Available Quantity
5023 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 127.17500
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LSR6B, we specialize in Honeywell Sensing and Productivity Solutions all series electronic components. LSR6B can be shipped within 24 hours after order. If you have any demands for LSR6B, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LSR6B Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LSR6B
| Internal Part Number | EIS-LSR6B | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| 3D Model | LSR6B.stp | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Snap Action, Limit Switches | |
| Series | LSR | |
| Packaging | Bulk | |
| Circuit | DPDT-DB | |
| Switch Function | On-Mom | |
| Current Rating | 10A (AC), 800mA (DC) | |
| Voltage Rating - AC | 120V | |
| Voltage Rating - DC | 115V | |
| Actuator Type | Side Rotary - No Lever | |
| Mounting Type | Chassis Mount | |
| Termination Style | Plug In | |
| Ingress Protection | - | |
| Features | - | |
| Operating Force, Torque | 1.7 in-lb | |
| Release Force | - | |
| Pretravel | 15° | |
| Differential Travel | 7° | |
| Overtravel | 60° | |
| Operating Position | - | |
| Mechanical Life | - | |
| Electrical Life | - | |
| Operating Temperature | -1°C ~ 121°C | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LSR6B | |
| Related Links | LS, LSR6B Datasheet, Honeywell Sensing and Productivity Solutions Distributor | |
