Linear LT1371IR#PBF
- Mfg. Part Number
- LT1371IR#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG MULT CONFIG INV ADJ D2PAK
- Datasheet Download
- LT1371IR#PBF.pdf
Availability of LT1371IR#PBF
Available Quantity
5183 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT1371IR#PBF, we specialize in Linear all series electronic components. LT1371IR#PBF can be shipped within 24 hours after order. If you have any demands for LT1371IR#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT1371IR#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT1371IR#PBF
| Internal Part Number | EIS-LT1371IR#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 50 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Up, Step-Down, Step-Up/Step-Down | |
| Output Configuration | Positive or Negative | |
| Topology | Buck, Boost, Cuk, Flyback, Forward Converter, SEPIC | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.7V | |
| Voltage - Input (Max) | 30V | |
| Voltage - Output (Min/Fixed) | 1.245V | |
| Voltage - Output (Max) | 35V (Switch) | |
| Current - Output | 3A (Switch) | |
| Frequency - Switching | 500kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | 0°C ~ 70°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | TO-263-8, D²Pak (7 Leads + Tab), TO-263CA | |
| Supplier Device Package | D2PAK-7 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT1371IR#PBF | |
| Related Links | LT1371, LT1371IR#PBF Datasheet, Linear Distributor | |
