Linear LT1780ISW#TR
- Mfg. Part Number
- LT1780ISW#TR
- Manufacturer
- Linear
- Product Category
- Interface - Drivers, Receivers, Transceivers
- Brief Description
- IC TXRX 5V RS232 DUAL LP 18SOIC
- Datasheet Download
- LT1780ISW#TR.pdf
Availability of LT1780ISW#TR
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.91949
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LT1780ISW#TR, we specialize in Linear all series electronic components. LT1780ISW#TR can be shipped within 24 hours after order. If you have any demands for LT1780ISW#TR, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LT1780ISW#TR Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LT1780ISW#TR
| Internal Part Number | EIS-LT1780ISW#TR | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Interface - Drivers, Receivers, Transceivers | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Type | Transceiver | |
| Protocol | RS232 | |
| Number of Drivers/Receivers | 2/2 | |
| Duplex | Full | |
| Receiver Hysteresis | 400mV | |
| Data Rate | 250KBd | |
| Voltage - Supply | 4.5 V ~ 5.5 V | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 18-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 18-SOIC | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LT1780ISW#TR | |
| Related Links | LT1780, LT1780ISW#TR Datasheet, Linear Distributor | |
LT1780ISW#TR Details Description
