Linear LTC1550CGN#PBF
- Mfg. Part Number
- LTC1550CGN#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG SWTCHD CAP INV ADJ 16SSOP
- Datasheet Download
- LTC1550CGN#PBF.pdf
Availability of LTC1550CGN#PBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.80000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC1550CGN#PBF, we specialize in Linear all series electronic components. LTC1550CGN#PBF can be shipped within 24 hours after order. If you have any demands for LTC1550CGN#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC1550CGN#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC1550CGN#PBF
| Internal Part Number | EIS-LTC1550CGN#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Up/Step-Down | |
| Output Configuration | Negative | |
| Topology | Charge Pump | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 6.5V | |
| Voltage - Output (Min/Fixed) | -1.24V | |
| Voltage - Output (Max) | -6.1V | |
| Current - Output | 10mA | |
| Frequency - Switching | 900kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | 0°C ~ 70°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 16-SSOP (0.154", 3.90mm Width) | |
| Supplier Device Package | 16-SSOP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC1550CGN#PBF | |
| Related Links | LTC1550, LTC1550CGN#PBF Datasheet, Linear Distributor | |
LTC1550CGN#PBF Details Description
