Linear LTC2242IUP-10#PBF
- Mfg. Part Number
- LTC2242IUP-10#PBF
- Manufacturer
- Linear
- Product Category
- Data Acquisition - Analog to Digital Converters (ADC)
- Brief Description
- IC ADC 10BIT 250MSPS 64-QFN
- Datasheet Download
- LTC2242IUP-10#PBF.pdf
Availability of LTC2242IUP-10#PBF
Available Quantity
5060 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 56.43990
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC2242IUP-10#PBF, we specialize in Linear all series electronic components. LTC2242IUP-10#PBF can be shipped within 24 hours after order. If you have any demands for LTC2242IUP-10#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC2242IUP-10#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC2242IUP-10#PBF
| Internal Part Number | EIS-LTC2242IUP-10#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | High Speed ADCs | |
| Standard Package | 40 | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Analog to Digital Converters (ADC) | |
| Series | - | |
| Packaging | Tube | |
| Number of Bits | 10 | |
| Sampling Rate (Per Second) | 250M | |
| Number of Inputs | 1 | |
| Input Type | Differential | |
| Data Interface | LVDS - Parallel, Parallel | |
| Configuration | S/H-ADC | |
| Ratio - S/H:ADC | 1:1 | |
| Number of A/D Converters | 1 | |
| Architecture | Pipelined | |
| Reference Type | External, Internal | |
| Voltage - Supply, Analog | 2.375 V ~ 2.625 V | |
| Voltage - Supply, Digital | 2.375 V ~ 2.625 V | |
| Features | - | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 64-WFQFN Exposed Pad | |
| Supplier Device Package | 64-QFN (9x9) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC2242IUP-10#PBF | |
| Related Links | LTC2242I, LTC2242IUP-10#PBF Datasheet, Linear Distributor | |
