Linear LTC3260IDE#PBF
- Mfg. Part Number
- LTC3260IDE#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG CHARGE PUMP DUAL 14DFN
- Datasheet Download
- LTC3260IDE#PBF.pdf
Availability of LTC3260IDE#PBF
Available Quantity
5254 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.75000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3260IDE#PBF, we specialize in Linear all series electronic components. LTC3260IDE#PBF can be shipped within 24 hours after order. If you have any demands for LTC3260IDE#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3260IDE#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3260IDE#PBF
| Internal Part Number | EIS-LTC3260IDE#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 91 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Ratiometric | |
| Output Configuration | Positive and Negative (Dual Rail) | |
| Topology | Charge Pump | |
| Output Type | Fixed | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 32V | |
| Voltage - Output (Min/Fixed) | -Vin | |
| Voltage - Output (Max) | - | |
| Current - Output | 100mA | |
| Frequency - Switching | 50kHz ~ 500kHz | |
| Synchronous Rectifier | No | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-WFDFN Exposed Pad | |
| Supplier Device Package | 14-DFN (4x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3260IDE#PBF | |
| Related Links | LTC3260, LTC3260IDE#PBF Datasheet, Linear Distributor | |
LTC3260IDE#PBF Details Description
