Linear LTC3614HUDD#PBF
- Mfg. Part Number
- LTC3614HUDD#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK ADJ 4A SYNC 24QFN
- Datasheet Download
- LTC3614HUDD#PBF.pdf
Availability of LTC3614HUDD#PBF
Available Quantity
5136 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.46000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3614HUDD#PBF, we specialize in Linear all series electronic components. LTC3614HUDD#PBF can be shipped within 24 hours after order. If you have any demands for LTC3614HUDD#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3614HUDD#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3614HUDD#PBF
| Internal Part Number | EIS-LTC3614HUDD#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | LTC3612,14,15,16 Design Updates 28/Jun/2014 | |
| Standard Package | 73 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.25V | |
| Voltage - Input (Max) | 5.5V | |
| Voltage - Output (Min/Fixed) | 0.6V | |
| Voltage - Output (Max) | 5.5V | |
| Current - Output | 4A | |
| Frequency - Switching | 300kHz ~ 4MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -55°C ~ 150°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-WFQFN Exposed Pad | |
| Supplier Device Package | 24-QFN (3x5) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3614HUDD#PBF | |
| Related Links | LTC3614, LTC3614HUDD#PBF Datasheet, Linear Distributor | |
