Linear LTC3622EDE#PBF
- Mfg. Part Number
- LTC3622EDE#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Regulators
- Brief Description
- IC REG BUCK ADJ 1A DL SYNC 14DFN
- Datasheet Download
- LTC3622EDE#PBF.pdf
Availability of LTC3622EDE#PBF
Available Quantity
5141 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 4.55000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3622EDE#PBF, we specialize in Linear all series electronic components. LTC3622EDE#PBF can be shipped within 24 hours after order. If you have any demands for LTC3622EDE#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3622EDE#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3622EDE#PBF
| Internal Part Number | EIS-LTC3622EDE#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Design Note 537 | |
| PCN Design/Specification | LTC3622(-2) Die Update 06/Nov/2014 | |
| Standard Package | 91 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Regulators | |
| Series | - | |
| Packaging | Tube | |
| Function | Step-Down | |
| Output Configuration | Positive | |
| Topology | Buck | |
| Output Type | Adjustable | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 2.7V | |
| Voltage - Input (Max) | 17V | |
| Voltage - Output (Min/Fixed) | 0.6V | |
| Voltage - Output (Max) | 17V | |
| Current - Output | 1A | |
| Frequency - Switching | 1MHz | |
| Synchronous Rectifier | Yes | |
| Operating Temperature | -40°C ~ 125°C (TJ) | |
| Mounting Type | Surface Mount | |
| Package / Case | 14-WFDFN Exposed Pad | |
| Supplier Device Package | 14-DFN (4x3) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3622EDE#PBF | |
| Related Links | LTC3622, LTC3622EDE#PBF Datasheet, Linear Distributor | |
LTC3622EDE#PBF Details Description
