Linear LTC3863EMSE#PBF
- Mfg. Part Number
- LTC3863EMSE#PBF
- Manufacturer
- Linear
- Product Category
- PMIC - Voltage Regulators - DC DC Switching Controllers
- Brief Description
- IC REG CTRLR BUCK PWM 12MSOP
- Datasheet Download
- LTC3863EMSE#PBF.pdf
Availability of LTC3863EMSE#PBF
Available Quantity
5283 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.50000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTC3863EMSE#PBF, we specialize in Linear all series electronic components. LTC3863EMSE#PBF can be shipped within 24 hours after order. If you have any demands for LTC3863EMSE#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTC3863EMSE#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTC3863EMSE#PBF
| Internal Part Number | EIS-LTC3863EMSE#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | LTC3863 Overview | |
| PCN Design/Specification | LTC3863/LTC3864 Die Update 27/Oct/2014 | |
| Standard Package | 37 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Voltage Regulators - DC DC Switching Controllers | |
| Series | - | |
| Packaging | Tube | |
| Number of Outputs | 1 | |
| Frequency - Max | 810kHz | |
| Duty Cycle | - | |
| Voltage - Supply | 3.5 V ~ 60 V | |
| Buck | No | |
| Boost | No | |
| Flyback | No | |
| Inverting | Yes | |
| Doubler | No | |
| Divider | No | |
| Cuk | No | |
| Isolated | No | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 12-TSSOP (0.118", 3.00mm Width) Exposed Pad | |
| Supplier Device Package | 12-MSOP-EP | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTC3863EMSE#PBF | |
| Related Links | LTC3863, LTC3863EMSE#PBF Datasheet, Linear Distributor | |
LTC3863EMSE#PBF Details Description
