Linear LTM4628EY#PBF
- Mfg. Part Number
- LTM4628EY#PBF
- Manufacturer
- Linear
- Product Category
- DC DC Converters
- Brief Description
- IC DC/DC UMODULE 16A 144-BGA
- Datasheet Download
- LTM4628EY#PBF.pdf
Availability of LTM4628EY#PBF
Available Quantity
5145 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 25.56990
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTM4628EY#PBF, we specialize in Linear all series electronic components. LTM4628EY#PBF can be shipped within 24 hours after order. If you have any demands for LTM4628EY#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTM4628EY#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTM4628EY#PBF
| Internal Part Number | EIS-LTM4628EY#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Featured Product | µModule Products Power Management Solutions Guide – Linear Technology | |
| Reference Design Library | DC1663A: 1.2V @ 8A, 1.5V @ 8A, 4.5 ~ 26.5V in | |
| Standard Package | 119 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | µModule® | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 2 | |
| Voltage - Input (Min) | 4.5V | |
| Voltage - Input (Max) | 26.5V | |
| Voltage - Output 1 | 0.6 ~ 5.5 V | |
| Voltage - Output 2 | 0.6 ~ 5.5 V | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 8A, 8A | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | OCP, OVP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 144-BGA | |
| Size / Dimension | 0.59" L x 0.59" W x 0.17" H (15.0mm x 15.0mm x 4.3mm) | |
| Operating Temperature | -40°C ~ 125°C | |
| Efficiency | - | |
| Power (Watts) - Max | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTM4628EY#PBF | |
| Related Links | LTM462, LTM4628EY#PBF Datasheet, Linear Distributor | |
