Linear LTM8045MPY
- Mfg. Part Number
- LTM8045MPY
- Manufacturer
- Linear
- Product Category
- DC DC Converters
- Brief Description
- DC-DC CONVRT +/-2.5V +/-15V 0.7A
- Datasheet Download
- LTM8045MPY.pdf
Availability of LTM8045MPY
Available Quantity
5293 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 20.84000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTM8045MPY, we specialize in Linear all series electronic components. LTM8045MPY can be shipped within 24 hours after order. If you have any demands for LTM8045MPY, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTM8045MPY Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTM8045MPY
| Internal Part Number | EIS-LTM8045MPY | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 273 | |
| Category | Power Supplies - Board Mount | |
| Family | DC DC Converters | |
| Series | µModule® | |
| Packaging | Tray | |
| Type | Non-Isolated PoL Module | |
| Number of Outputs | 1 | |
| Voltage - Input (Min) | 2.8V | |
| Voltage - Input (Max) | 18V | |
| Voltage - Output 1 | -2.5 ~ -15 V, 2.5 ~ 15 V | |
| Voltage - Output 2 | - | |
| Voltage - Output 3 | - | |
| Current - Output (Max) | 700mA | |
| Power (Watts) - Manufacture Series | - | |
| Voltage - Isolation | - | |
| Features | OTP, UVLO | |
| Mounting Type | Surface Mount | |
| Package / Case | 40-BBGA | |
| Size / Dimension | 0.44" L x 0.25" W x 0.19" H (11.3mm x 6.3mm x 4.9mm) | |
| Operating Temperature | -55°C ~ 125°C | |
| Efficiency | - | |
| Power (Watts) - Max | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTM8045MPY | |
| Related Links | LTM80, LTM8045MPY Datasheet, Linear Distributor | |
