Linear LTP5900IPC-WHMA1A2#PBF
- Mfg. Part Number
- LTP5900IPC-WHMA1A2#PBF
- Manufacturer
- Linear
- Product Category
- RF Transceiver Modules
- Brief Description
- MOD WIRELESSHART MOTE 2.4GHZ
- Datasheet Download
- LTP5900IPC-WHMA1A2#PBF.pdf
Availability of LTP5900IPC-WHMA1A2#PBF
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 64.40000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LTP5900IPC-WHMA1A2#PBF, we specialize in Linear all series electronic components. LTP5900IPC-WHMA1A2#PBF can be shipped within 24 hours after order. If you have any demands for LTP5900IPC-WHMA1A2#PBF, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LTP5900IPC-WHMA1A2#PBF Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LTP5900IPC-WHMA1A2#PBF
| Internal Part Number | EIS-LTP5900IPC-WHMA1A2#PBF | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Featured Product | SmartMesh IP™ Embedded Products SmartMesh® WirelessHART Embedded Products | |
| PCN Design/Specification | Change of Crystals 17/Jun/2015 | |
| Standard Package | 12 | |
| Category | RF/IF and RFID | |
| Family | RF Transceiver Modules | |
| Series | Dust Networks®, SmartMesh®, WirelessHART | |
| Packaging | Tray | |
| RF Family/Standard | 802.15.4 | |
| Protocol | - | |
| Modulation | - | |
| Frequency | 2.4GHz ~ 2.48GHz | |
| Data Rate | 250kbps | |
| Power - Output | 8dBm | |
| Sensitivity | -95dBm | |
| Serial Interfaces | SPI, UART | |
| Antenna Type | Not Included, MMCX | |
| Memory Size | - | |
| Voltage - Supply | 2.75 V ~ 3.76 V | |
| Current - Receiving | 4.5mA | |
| Current - Transmitting | 9.7mA | |
| Mounting Type | Through Hole | |
| Operating Temperature | -40°C ~ 85°C | |
| Package / Case | 22-DIP Module | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LTP5900IPC-WHMA1A2#PBF | |
| Related Links | LTP5900IPC-, LTP5900IPC-WHMA1A2#PBF Datasheet, Linear Distributor | |
LTP5900IPC-WHMA1A2#PBF Details Description
