Power Integrations LYT4313L
- Mfg. Part Number
- LYT4313L
- Manufacturer
- Power Integrations
- Product Category
- PMIC - LED Drivers
- Brief Description
- IC LED Driver AC DC Offline Switcher Triac Dimming 2.72A (Switch) eSIP-7F
- Datasheet Download
- LYT4313L.pdf
Availability of LYT4313L
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of LYT4313L, we specialize in Power Integrations all series electronic components. LYT4313L can be shipped within 24 hours after order. If you have any demands for LYT4313L, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- LYT4313L Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
LYT4313L
| Internal Part Number | EIS-LYT4313L | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| Reference Design Library | RDK-347: 34V @ 370mA, 90 ~ 132 VAC DER-364: 350mA @ 44V Max, 90 ~ 132VAC in DER-357: 170mA @ 75V Max, 90 ~ 132VAC in | |
| PCN Other | Multiple Changes 11/Nov/2014 | |
| Standard Package | 48 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Series | LYTSwitch™-4 | |
| Packaging | Tube | |
| Type | AC DC Offline Switcher | |
| Topology | Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost) | |
| Internal Switch(s) | Yes | |
| Number of Outputs | 1 | |
| Voltage - Supply (Min) | 85VAC | |
| Voltage - Supply (Max) | 132VAC | |
| Voltage - Output | - | |
| Current - Output / Channel | 2.72A (Switch) | |
| Frequency | 132kHz | |
| Dimming | Triac | |
| Applications | - | |
| Operating Temperature | -40°C ~ 150°C (TJ) | |
| Mounting Type | Through Hole | |
| Package / Case | 7-SSIP, 6 Leads, Exposed Pad, Formed Leads | |
| Supplier Device Package | eSIP-7F | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | LYT4313L | |
| Related Links | LYT4, LYT4313L Datasheet, Power Integrations Distributor | |
LYT4313L Details Description
