NKK Switches M2B15BA5W03-CB
- Mfg. Part Number
- M2B15BA5W03-CB
- Manufacturer
- NKK Switches
- Product Category
- Pushbutton Switches
- Brief Description
- SWITCH PUSHBUTTON SPDT 1A 125V
- Datasheet Download
- M2B15BA5W03-CB.pdf
Availability of M2B15BA5W03-CB
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 5.38000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M2B15BA5W03-CB, we specialize in NKK Switches all series electronic components. M2B15BA5W03-CB can be shipped within 24 hours after order. If you have any demands for M2B15BA5W03-CB, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M2B15BA5W03-CB Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M2B15BA5W03-CB
| Internal Part Number | EIS-M2B15BA5W03-CB | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Switch Basics Tough Environments 3D CAD Models | |
| RoHS Information | Series, Cert of Compliance | |
| 3D Model | M2B15BA5W03-CB | |
| PCN Design/Specification | M Series Toggles, rockers, Pushbuttons CSA Mark Size 23/Jul/2015 | |
| Standard Package | 1 | |
| Category | Switches | |
| Family | Pushbutton Switches | |
| Series | M2 | |
| Packaging | Bulk | |
| Type | Standard | |
| Circuit | SPDT | |
| Switch Function | On-Mom | |
| Current Rating | 1A (AC/DC) | |
| Voltage Rating - AC | 125V | |
| Voltage Rating - DC | 30V | |
| Actuator Type | Round, Button | |
| Color - Actuator/Cap | White | |
| Illumination Type, Color | - | |
| Illumination Voltage (Nominal) | - | |
| Mounting Type | Through Hole | |
| Termination Style | PC Pin | |
| Ingress Protection | - | |
| Features | Process Sealed | |
| Panel Cutout Dimensions | - | |
| Operating Temperature | -30°C ~ 85°C | |
| Mechanical Life | 200,000 Cycles | |
| Electrical Life | 25,000 Cycles | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M2B15BA5W03-CB | |
| Related Links | M2B15BA, M2B15BA5W03-CB Datasheet, NKK Switches Distributor | |
