Renesas Electronics America M30805FGGP#U5
- Mfg. Part Number
- M30805FGGP#U5
- Manufacturer
- Renesas Electronics America
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 16BIT 256KB FLASH 144LQFP
- Datasheet Download
- M30805FGGP#U5.pdf
Availability of M30805FGGP#U5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M30805FGGP#U5, we specialize in Renesas Electronics America all series electronic components. M30805FGGP#U5 can be shipped within 24 hours after order. If you have any demands for M30805FGGP#U5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M30805FGGP#U5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M30805FGGP#U5
| Internal Part Number | EIS-M30805FGGP#U5 | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Electromagnetic Noise Reduction Techniques Part 1 | |
| Design Resources | Development Tool Selector | |
| Featured Product | Flasher Series of Production Tools | |
| PCN Obsolescence/ EOL | Multiple Devices 16/Jun/2014 Multiple Devices 08/Dec/2014 | |
| Standard Package | 1 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | M16C™ M16C/80 | |
| Packaging | Tray | |
| Core Processor | M16C/80 | |
| Core Size | 16-Bit | |
| Speed | 20MHz | |
| Connectivity | SIO, UART/USART | |
| Peripherals | DMA, PWM, WDT | |
| Number of I/O | 121 | |
| Program Memory Size | 256KB (256K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 20K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | |
| Data Converters | A/D 10x10b, D/A 2x8b | |
| Oscillator Type | Internal | |
| Operating Temperature | -20°C ~ 85°C | |
| Package / Case | 144-LQFP | |
| Supplier Device Package | 144-LFQFP (20x20) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M30805FGGP#U5 | |
| Related Links | M30805, M30805FGGP#U5 Datasheet, Renesas Electronics America Distributor | |
