Vishay/Dale M55342K06B2B74RT5
.jpg)
- Mfg. Part Number
- M55342K06B2B74RT5
- Manufacturer
- Vishay/Dale
- Product Category
- Chip Resistor - Surface Mount
- Brief Description
- RES SMD 2.74KOHM 0.1% 0.15W 0805
- Datasheet Download
- M55342K06B2B74RT5.pdf
Availability of M55342K06B2B74RT5
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 1.80874
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of M55342K06B2B74RT5, we specialize in Vishay/Dale all series electronic components. M55342K06B2B74RT5 can be shipped within 24 hours after order. If you have any demands for M55342K06B2B74RT5, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- M55342K06B2B74RT5 Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
M55342K06B2B74RT5
| Internal Part Number | EIS-M55342K06B2B74RT5 | |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Standard Package | 500 | |
| Category | Resistors | |
| Family | Chip Resistor - Surface Mount | |
| Series | Military, MIL-PRF-55342, RM0705 | |
| Packaging | Tape & Reel (TR) | |
| Resistance (Ohms) | 2.74k | |
| Tolerance | ±0.1% | |
| Power (Watts) | 0.15W | |
| Composition | Thin Film | |
| Features | Military, Non-Inductive | |
| Temperature Coefficient | ±100ppm/°C | |
| Package / Case | 0805 (2012 Metric) | |
| Supplier Device Package | 0705 | |
| Size / Dimension | 0.080" L x 0.050" W (2.03mm x 1.27mm) | |
| Height | 0.033" (0.84mm) | |
| Number of Terminations | 2 | |
| Failure Rate | R (0.01%) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | M55342K06B2B74RT5 | |
| Related Links | M55342K0, M55342K06B2B74RT5 Datasheet, Vishay/Dale Distributor | |
