Maxim Integrated MAX8753EVKIT
- Mfg. Part Number
- MAX8753EVKIT
- Manufacturer
- Maxim Integrated
- Product Category
- Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
- Brief Description
- KIT EVALUATION FOR MAX8753
- Datasheet Download
- MAX8753EVKIT.pdf
Availability of MAX8753EVKIT
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 76.50000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MAX8753EVKIT, we specialize in Maxim Integrated all series electronic components. MAX8753EVKIT can be shipped within 24 hours after order. If you have any demands for MAX8753EVKIT, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MAX8753EVKIT Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MAX8753EVKIT
| Internal Part Number | EIS-MAX8753EVKIT | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| Standard Package | 1 | |
| Category | Programmers, Development Systems | |
| Family | Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS | |
| Series | - | |
| Main Purpose | DC/DC, Step Up with LDO | |
| Outputs and Type | 4, Non-Isolated | |
| Power - Output | - | |
| Voltage - Output | 2.5V, 9V, 24V, -11V | |
| Current - Output | 600mA, 160mA, 20mA, 20mA | |
| Voltage - Input | 2.6 V ~ 5.5 V | |
| Regulator Topology | Boost | |
| Frequency - Switching | 1MHz | |
| Board Type | Fully Populated | |
| Supplied Contents | Board | |
| Utilized IC / Part | MAX8753 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MAX8753EVKIT | |
| Related Links | MAX875, MAX8753EVKIT Datasheet, Maxim Integrated Distributor | |
MAX8753EVKIT Details Description
