ON Semiconductor MC100EL30DWR2G
- Mfg. Part Number
- MC100EL30DWR2G
- Manufacturer
- ON Semiconductor
- Product Category
- Logic - Flip Flops
- Brief Description
- IC D-TYPE POS TRG TRPL 20SOIC
- Datasheet Download
- MC100EL30DWR2G.pdf
Availability of MC100EL30DWR2G
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 6.65000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC100EL30DWR2G, we specialize in ON Semiconductor all series electronic components. MC100EL30DWR2G can be shipped within 24 hours after order. If you have any demands for MC100EL30DWR2G, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC100EL30DWR2G Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC100EL30DWR2G
| Internal Part Number | EIS-MC100EL30DWR2G | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Integrated Circuits (ICs) | |
| Family | Logic - Flip Flops | |
| Series | 100EL | |
| Packaging | Tape & Reel (TR) | |
| Function | Set(Preset) and Reset | |
| Type | D-Type | |
| Output Type | Differential | |
| Number of Elements | 3 | |
| Number of Bits per Element | 1 | |
| Frequency - Clock | 1.2GHz | |
| Max Propagation Delay @ V, Max CL | - | |
| Trigger Type | Positive Edge | |
| Current - Output High, Low | - | |
| Voltage - Supply | -4.2 V ~ -5.7 V | |
| Current - Quiescent | 62mA | |
| Input Capacitance | - | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 20-SOIC (0.295", 7.50mm Width) | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC100EL30DWR2G | |
| Related Links | MC100EL, MC100EL30DWR2G Datasheet, ON Semiconductor Distributor | |
