NXP Semiconductors/Freescale Semiconductor, Inc. MC9S08SH32MWL
- Mfg. Part Number
- MC9S08SH32MWL
- Manufacturer
- NXP Semiconductors/Freescale Semiconductor, Inc.
- Product Category
- Embedded - Microcontrollers
- Brief Description
- IC MCU 8BIT 32KB FLASH 28SOIC
- Datasheet Download
- MC9S08SH32MWL.pdf
Availability of MC9S08SH32MWL
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 2.10000
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MC9S08SH32MWL, we specialize in NXP Semiconductors/Freescale Semiconductor, Inc. all series electronic components. MC9S08SH32MWL can be shipped within 24 hours after order. If you have any demands for MC9S08SH32MWL, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MC9S08SH32MWL Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MC9S08SH32MWL
| Internal Part Number | EIS-MC9S08SH32MWL | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Development Tool Selector | |
| PCN Design/Specification | Multiple Devices Polyimide Removal 09/Jul/2013 MC9S08SH32,SH16 Datasheet Update 11/Apr/2014 Copper Wire Conversion 20/May/2014 | |
| Standard Package | 1,560 | |
| Category | Integrated Circuits (ICs) | |
| Family | Embedded - Microcontrollers | |
| Series | S08 | |
| Packaging | Tube | |
| Core Processor | S08 | |
| Core Size | 8-Bit | |
| Speed | 40MHz | |
| Connectivity | I²C, LIN, SCI, SPI | |
| Peripherals | LVD, POR, PWM, WDT | |
| Number of I/O | 23 | |
| Program Memory Size | 32KB (32K x 8) | |
| Program Memory Type | FLASH | |
| EEPROM Size | - | |
| RAM Size | 1K x 8 | |
| Voltage - Supply (Vcc/Vdd) | 2.7 V ~ 5.5 V | |
| Data Converters | A/D 16x10b | |
| Oscillator Type | Internal | |
| Operating Temperature | -40°C ~ 125°C | |
| Package / Case | 28-SOIC (0.295", 7.50mm Width) | |
| Supplier Device Package | 28-SOIC W | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MC9S08SH32MWL | |
| Related Links | MC9S08, MC9S08SH32MWL Datasheet, NXP Semiconductors/Freescale Semiconductor, Inc. Distributor | |
