Cornell Dubilier Electronics MCM01-009EF271J-F
- Mfg. Part Number
- MCM01-009EF271J-F
- Manufacturer
- Cornell Dubilier Electronics
- Product Category
- Mica and PTFE Capacitors
- Brief Description
- CAP MICA 270PF 5% 1KV SMD
- Datasheet Download
- MCM01-009EF271J-F.pdf
Availability of MCM01-009EF271J-F
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- $ 3.41700
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCM01-009EF271J-F, we specialize in Cornell Dubilier Electronics all series electronic components. MCM01-009EF271J-F can be shipped within 24 hours after order. If you have any demands for MCM01-009EF271J-F, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCM01-009EF271J-F Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCM01-009EF271J-F
| Internal Part Number | EIS-MCM01-009EF271J-F | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) | |
| Production Status (Lifecycle) | In Production | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 100 | |
| Category | Capacitors | |
| Family | Mica and PTFE Capacitors | |
| Series | MCM01 | |
| Packaging | Bulk | |
| Capacitance | 270pF | |
| Tolerance | ±5% | |
| Voltage - Rated | 1000V (1kV) | |
| Dielectric Material | Mica | |
| Mounting Type | Surface Mount | |
| Package / Case | Nonstandard SMD | |
| Lead Spacing | - | |
| Operating Temperature | -55°C ~ 200°C | |
| Features | RF, High Frequency | |
| Size / Dimension | 0.460" L x 0.400" W (11.68mm x 10.16mm) | |
| Height - Seated (Max) | - | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCM01-009EF271J-F | |
| Related Links | MCM01-00, MCM01-009EF271J-F Datasheet, Cornell Dubilier Electronics Distributor | |
MCM01-009EF271J-F Details Description
