Fairchild Semiconductor MCT2SR2VM
- Mfg. Part Number
- MCT2SR2VM
- Manufacturer
- Fairchild Semiconductor
- Product Category
- Optoisolators - Transistor, Photovoltaic Output
- Brief Description
- OPTOISO 7.5KV TRANS W/BASE 6SMD
- Datasheet Download
- MCT2SR2VM.pdf
Availability of MCT2SR2VM
Available Quantity
5020 Pieces
Can ship today
Ship from: HONGKONG
Date Code: Newest Date Code
Manufacturer lead time 6 weeks
- Marketing Price
- N/A
- Our Price
- Quote by Email
EIS Components is the stocking Distributor of MCT2SR2VM, we specialize in Fairchild Semiconductor all series electronic components. MCT2SR2VM can be shipped within 24 hours after order. If you have any demands for MCT2SR2VM, Please kindly submit an RFQ here or send us an email. We will reply you as soon as possible.
- MCT2SR2VM Order Process
- Add Parts to RFQ form
- Submit RFQ
- We reply within 24 hours
- You confirm order
- Payment
- Ship out your order
Specifications of
MCT2SR2VM
| Internal Part Number | EIS-MCT2SR2VM | |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant | |
| Moisture Sensitivity Level (MSL) | ||
| Production Status (Lifecycle) | Obsolete / Discontinued | |
| Condition | New & Unused, Original Sealed | |
| Standard Package | 1,000 | |
| Category | Isolators | |
| Family | Optoisolators - Transistor, Photovoltaic Output | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Number of Channels | 1 | |
| Voltage - Isolation | 7500Vpk | |
| Current Transfer Ratio (Min) | 20% @ 10mA | |
| Current Transfer Ratio (Max) | - | |
| Turn On / Turn Off Time (Typ) | 2µs, 2µs | |
| Rise / Fall Time (Typ) | 2µs, 1.5µs | |
| Input Type | DC | |
| Output Type | Transistor with Base | |
| Voltage - Output (Max) | 30V | |
| Current - Output / Channel | 50mA | |
| Voltage - Forward (Vf) (Typ) | 1.25V | |
| Current - DC Forward (If) (Max) | 60mA | |
| Vce Saturation (Max) | 400mV | |
| Operating Temperature | -55°C ~ 100°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 6-SMD, Gull Wing | |
| Supplier Device Package | 6-SMD | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Alternative Part (Replacement) | MCT2SR2VM | |
| Related Links | MCT2, MCT2SR2VM Datasheet, Fairchild Semiconductor Distributor | |
MCT2SR2VM Details Description
